Pergola Twin Fly

DOUBLE FREE STANDING PERGOLA FLY

Main set includes: central column structures with a distance of 6 meters, roof part, mounting profiles.

Double pergola is an excellent solution for freestanding areas of outdoor cafes and restaurants. The design creates dense shade reducing the temperature under the canopy to comfortable 24-26 degrees. The sloping plane of the roof reinforces protection against rain, ensuring proper drainage. Convenient form allows you to arrange several entrances under the awning pergola, from different sides. Bright stylish design of the product attracts additional attention and guarantees increased facility attendance.

Price list

		Width (m)
		1 module				2 modules						3 modules
		3,0	3,5	4,0	4,5	4,5	5,0	6,0	7,0	8,0	9,0	9,0	10,0	11,0	12,0	13,5
Offset (m)	6,0	6 684	7 149	7 624	8 091	10 085	10 550	11 483	12 416	13 423	14 356	16 342	17 360	18 464	19 224	20 622
	7,0	7 046	7 536	8 037	8 627	10 628	11 119	12 100	13 080	14 148	15 161	17 219	18 304	19 485	20 259	21 729
	8,0	7 581	8 125	8 680	9 225	11 432	11 976	13 063	14 149	15 334	16 421	18 616	19 824	21 142	21 987	23 548
	Additional hangers
	9,0	8 763	9 330	9 912	10 480	13 203	13 771	14 906	16 042	17 285	18 421	21 131	22 405	23 801	24 659	26 362
	10,0	9 125	9 717	10 325	10 916	13 748	14 340	15 523	16 707	18 009	19 193	22 009	23 349	24 822	26 694	27 470
	12,0	10 028	10 698	11 386	12 056	15 101	15 771	17 111	18 450	19 930	21 270	24 296	25 826	27 514	28 474	30 483
All prices are in EUR excluding VAT

Pergola control options

RTS

RTS Altus (^0-50m2) RTS	400
Altus (^50-80m2) RTS	500
TANDEM (^80-150m2)	1200

Remote controls

Situo RTS Pure1k/5k Telis	50/90
RTS Patio1k/4k Telis RTS	80/110
Pure 16k	250

24 V LED LIGHTING

Diode panel

Recommended 1 bulb – 1^m2

Recommended for up to 150^m2 (500W) 600 €
(remote control ordered separately)

Recommended for up to 50^m2 (150W) 400 €
(remote control ordered separately)

Elements

Pergola design elements:
1. Moving beam component. Base (71x150mm, t:1.9mm), reaches up to 6 m.
2. Wall mounting profile, fastening of the moving beam with rigid hangers, additional beam for the fabric.
3. The roof is made of galvanized steel plate with a polymer coating whose colour matches that of the structure.
4. Tarpaulin frame. Larger with a cross section of 57×83 mm, smaller with 57×43 mm. Mounted at 40-50 cm intervals, connected wall aluminium connectors. There are no plastic elements in the holder and rails.
5. The fabric of the awning is made of composite material Blackout with a density of 760 g/m2. Manufacturer: Sattler (Austria).
Pergola control:
- Automation and remote controls are not included in the price of the pergola and are calculated separately.
Optional:
- LED panels with warm or cool light range integrated into the edges of the sheet. Price 20 €/pc.
- The cost of the dimmer is included when ordering LED lighting (depending on the control option chosen).
- Side column (included in the main set of free standing gazebos).
- Pergola painting. Additional 10% are paid from the base price.
- Semi-transparent fabric Soltis Waterprof (Serge Ferrari) – price 30 ^€/m2; Flexlight Lodge (Stam, Serge Ferrari) – price 10 ^€/m2.
